⚙️ PMSM Controller (1250W / 60A) – For IPM Motors This 60A PMSM controller is precisely tuned for 1250W Interior Permanent Magnet (IPM) motors, offering smart torque delivery, ultra-smooth ride feel, and superior battery efficiency. Ideal for high-performance e-rickshaws and utility EVs that demand stability, safety, and endurance in everyday operations. ✅ Technical Specifications: Rated Current: 60 Amps Motor Power: 1250W PMSM (IPM) Operating Voltage: 48V / 60V (72V optional) Control Algorithm: FOC (Field Oriented Control) with vector torque control Motor Feedback: Hall sensor & sensorless compatible Throttle: 3-wire / 5-wire analog throttle input Speed Modes: 3-level speed selection + reverse Braking Support: Regenerative braking (programmable strength) E-brake input & brake cut-off support Reverse Mode: Integrated soft reverse with buzzer option Display Interface: UART / CAN support for digital dashboards Cooling: Passive air-cooled with large aluminum heat sink Enclosure: Die-cast aluminum, IP65 waterproof/dustproof Protections: Overcurrent & short circuit protection Battery undervoltage & surge protection Stall detection Controller overheat auto derating Safe start logic 🛠️ Features & Benefits: ⚡ High-efficiency FOC technology = longer range per charge 🔇 Silent and ripple-free acceleration 🚀 Smooth hill starts and torque-rich low-speed performance 🔋 Battery-friendly design with energy recovery via regen braking 🧠 Diagnostics-ready for future IoT and BMS upgrades 🇮🇳 Built for Indian urban and semi-urban driving environments 🧭 Recommended for 4-passenger e-rickshaws, light cargo carriers, and smart EVs needing refined drive control and power optimization.
